Microprocessor Flame Photo Meter

Model No

ZAP-1600

Range

Na: 0-100ppm Up to 250 meq/1, 1:100 dil.

K: :0-100ppmUp to 250 meq/1, 1:100 dil.

Ca: 0-100ppm Up to 250 meq/1, 1:100 dil.

Li : 0-100ppmUp to 250 meq/1, 1:100 dil.

Sensitivity

Na : 0.1ppm, K : 0.01ppm, Ca : 0.5ppm, Li : 10ppm

Optical Management

Simultaneous analysis of 3 elements.

Filter

Microprocessor Controlled Stepper Motor With.

Selection

0.5 KVA Stabilizer.

Units

Ppm, mg and % age Selectable

Reproductively

+1% FS +1 Digits

Curve Fit Accuracy

+2% of FS

Display

Large LCD Display 20x4 lines graph through RS-232

Aspiration

4-5 Second.

Time Scale Range

0 to 100% Sensitivity for full Scale.

Flame System

LPG& Dry Oil Free air

Detector

Photodiode

Calibration

Up to 5 point Calibration With CurveFitting Software

Gas Control

Adjustable With Knob

Ignition

Auto ignition

System Fuel Gas

LPG

Burner

Stainless Steel

Dimensions

365x 245x 220 mm Approx. (LxBxH)

Printer

Provision for attachment of Dot- Matrix Printer of HP

LaserJet/ inkjet printer (non-win printers) with Getronics parallel interface

RS-232 interface

RS-232 Connector interface available (PC Software at extra Cost)

Air Compressor

With built in Regulator & Air filter to deliver Stable & Moisture / oil free supply @ 1 kg /cm.cm

Air Supply

By oil Free mill. Compressor unit with pressure regulator

Weight

Main Unit : 8 kg ( Approx), Compressor : 6.5 Kg. (Approx)

Power Supply

95 to 270 V AC 50-60 Hz With inbuilt Stabilizer.

Blank Air Supply

By oil controlled by precision regulator

Combustion Gas

LPG Controlled by precision regulator.

Power

230V + 10?, 50 Hz

Dimension

270Wx 192Hx 240D mm

Weight

6.25 Kg (Approx)
